ULTRASONIC THICKNESS GAUGE UM-2D
Operating Principle
Standard mode: P-E (pulse-echo) method with dual-crystal probes
Coating mode: E-E (echo-echo) method with dual-crystal probes
Measuring range:
1.0mm to 300mm in standard mode
3.0mm to 18.0mm in through coating mode
Depending on probe, material and surface condition
Units and Resolution:
Mm - 0.01, 0.01
Inches - 0.001, 0.01
Probe Zero Adjustment:
Selectable: 1-point calibration: normal measurement
2-point calibration: curve surface measurement or other special application with a high precision
V-path correction:
Automatic
Measuring error:
Up to 10mm: ±0.05mm
Above 10mm: ±(0.5%H+0.01)mm
Repeatability:
±0.05mm
Display:
128×64 dot-matrix LCD screen with EL backlight (42mm×57mm)
Measurement update rate:
4 Hz
Material velocity range:
1000 -- 9999 m/s;
Data logger capacity:
Up to 500 readings can be divided into a maximum of 5 files (user-selectable)
Operating language:
English and Chinese
Operating time:
Up to 200 hours (without backlight) with alkaline batteries, depending on operating mode
Power:
Two 1.5V AA alkaline batteries (Warning with low battery voltage)
Auto shut-off:
After 5 minutes of non-use
Operating temperature:
-10℃ to +50℃; (Specification to -20℃ on request)
Size:
149mm×73mm×32mm (H×W×D)
Weight:
200g; 7oz (including batteries)
Standard Package:
UM-2D thickness gauge
Standard probe (PT-08)
Carrying case
Two 1.5V AA alkaline batteries
Couplant
Operating manual
Certification of quality
Packaging list
Optional Accessories:
Attachable Rubber Sheath
Numerous special probes on request
Couplants and high-temperature couplant
4-step/5-step/6-step calibration block
Application software with Data transmission cable
